qplotmarker

QPlotMarker – an interactive marker for QChart (Qt). Supports color and orientation (vertical/horizontal) changes, snaps to data points, and displays intersection coordinates.

Install

You must have installed project dependencies

1. Clone repository

git clone https://github.com/Mark194/qplotmarker

2. Go to directory

cd qplotmarker

3. Create and go to the build directory

mkdir build

cd build

4. Project configuration via CMake

cmake ..

If you need to specify a specific generator, use

cmake -G "Visual Studio 17 2022" ..

If you want to configure the library as static, add the option

-DBUILD_SHARED_LIBS=OFF

5. Build project

cmake --build .

6. Installing the library into the system

cmake --install .

By default, installation goes to /usr/local/ on Linux/macOS or C:\Program Files (x86)\ on Windows. To change the path, specify

-DCMAKE_INSTALL_PREFIX=/your/path

Integration

QMake Integration

1. Add include path

INCLUDEPATH += $$PWD/thirdparty/qplotmarker/include

2. Link static library

LIBS += -L$$PWD/thirdparty/qplotmarker/lib -lqplotmarker

OR compile sources directly (if needed)

SOURCES += $$PWD/thirdparty/qplotmarker/src/.cpp HEADERS += $$PWD/thirdparty/qplotmarker/include/.h

CMake Integration

Method 1: Using find_package (Recommended if installed system-wide)

cmake

find_package(qplotmarker REQUIRED)

target_link_libraries(your_target PRIVATE qplotmarker::qplotmarker)

Method 2: Manual configuration (For custom locations)

# For header files

target_include_directories(your_target PRIVATE
    path/to/qplotmarker/include
)

# For static library
target_link_libraries(your_target PRIVATE
    path/to/qplotmarker/lib/libqplotmarker.a
)

# Or for shared library
target_link_libraries(your_target PRIVATE
    path/to/qplotmarker/lib/libqplotmarker.so

Method 3: Using FetchContent (For direct GitHub integration)

include(FetchContent)
FetchContent_Declare(
    qplotmarker
    GIT_REPOSITORY https://github.com/Mark194/qplotmarker.git
    GIT_TAG        v1.0.0
)
FetchContent_MakeAvailable(qplotmarker)
target_link_libraries(your_target PRIVATE qplotmarker)

Support

If you have any difficulties or questions about using the package, create a discussion in this repository or write to email

Dependencies

• Qt Core: Version 5.15.2+ or 6.4.2+
• Required Modules:
  • QtCharts (for plotting functionality)
  • QtSvg (for SVG support)
• Compiler:
  • Qt5: GCC 7+, Clang 6+, MSVC 2017 (v19.16+)
  • Qt6: GCC 9+, Clang 10+, MSVC 2019 (v19.28+)
• Additional Notes:
  • On Windows: MSVC is recommended (MinGW may have issues with QtCharts)
  • On macOS: Xcode 12+ required for Qt6
  • On Linux: Install libgl1-mesa-dev and other development tools

Found compatibility issues? Please report in Issues.

Examples

Ready-to-use code examples are available in the examples folder. These demonstrate:

• Basic usage of plotting functionality
• Advanced marker customization
• Integration with Qt widgets

Special Thanks

We would like to express our special gratitude to ShonZelno for their valuable contributions to this project, including:

• Active participation in development and testing
• Suggesting innovative ideas and improvements
• Helping to identify and fix critical issues

Your involvement made this library significantly better!
